Fiber Patch Cords (All Types)

Product Description

According to the Difference of Transmission Media, Fiber patch cord can be divided into common silicon-based optical fiber single-mode, multimode patch cord, also has other issues such as the fiber patch cord in plastic transmission medium; According to the connector structure, Fiber patch cord can be divided into: FC, SC, ST, LC, MTRJ, MPO, MU, SMA, FDDI, E2000, DIN4, D4 and other forms. Common fiber patch cord can be divided into FC-FC, FC-SC, FC-LC, FC-ST, SC-SC, SC-ST and so on .
Product Features
◆ PC, UPC, APC , varieties of grinding methods ◆ High reliability and stability, high return reflection loss and low insertion loss ◆ End Surface of plug core 400 times electrical test, good interchangeability, single mode or multimode optic fiber free selective
Product Application
◆data transmission, telecommunication network ◆CATV Test machine, broadband networks , Optical fiber, CATV
Product Parameter
Subject		Test Conditions	Single mode
Insertion Loss	UPC	1310nm/1550nm	≤0.1dB
	APC	1310nm/1550nm	≤0.1dB
Return Loss	UPC	1310nm/1550nm	≥55 dB
	APC	1310nm/1550nm	≥65 dB
Impact Test		1.8m Height，8times	<0.1 dB
Vibration Test		10-60Hz,1mm Full amplitude	<0.1 dB
Plug service life		More than 1000times	<0.1 dB
Tensile strength		2.0/3.0 50N 0.9 20N	<0.1 dB
High and low temperature cycle test		－45~85℃，96H	<0.2 dB
High temperature test		85℃，69H~96H	<0.2 dB
Low temperature test		-45℃，96H	<0.2 dB
Damp heat test		90-95%RH，96H	<0.2 dB
Rated temperature		-45~85℃	–
